| 모델 번호: | 슬롯 시리즈 | 유형: | 산업적 알루미늄 프로필 |
|---|---|---|---|
| 모양: | t- 프로필 | 등급: | 6000 시리즈 |
| 성질: | T3-T8 | 합금: | 합금 |
| 표면 마감: | 애노드 산화 | 합금 성분: | 6063 |
| 두께: | 1.2mm, 2.0mm, 3.0mm 등 | 표면: | 양극 화 된 분말 페인트 |
| 재료: | 6000SERIES 알루미늄 합금 | 슬롯 너비: | 6mm, 8mm, 10mm |
| 길이: | 6M/PC | 인장 강도: | ≥ 160mpa (T5), ≥ 205mpa (T6) |
| 항복 강도: | ≥ 110mpa (T5), ≥ 180mpa (T6) | ||
| 강조하다: | Anodized Aluminum Extrusion Profile,Bending Aluminium Profile System,Welding T-Slot Aluminum Profile |
||
| Product | T-Slot Aluminum Profiles Extrusion Frame |
|---|---|
| Material | 6000series aluminium alloy |
| Temper | T4, T5, T6 |
| Surface treatment | Powder Coating in RAL Color, Anodizing(AA10/15/20/25), Sandblasting, Brushing, Passivation, Silk screen, Mechanical/Chemical Polishing, Wood grain coated /Wooden transfer, Galvanise,(Nickel/Tin/Chrome/Copper) Plating, PVDF, Matt, etc. |
| Size | 40x40mm,30*30mm ,30*40mm , 25*25mm |
| Slot width | 6MM,8MM,10MM |
| Length | The standard length is 6m/pc, with professional cutting service available for custom sizes |
| Appearance | Normally square, round and T-shaped, or customized |
| Color | Wooden Grain, Aluminium Silver, Brilliant Black, Cream White, Chocolate Brown, Bronze, Champagne, Golden Yellow etc. |
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
|---|---|---|---|---|---|---|---|---|---|---|
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
| Alloy | Temper | Tensile strength | Yield strength | Elongation |
|---|---|---|---|---|
| 6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
| 6063 | T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% |
